KEYBOARD
- 49 or 61 note semi-weighted, velocity-sensitive
- Keyboard w/aftertouch
- 5 velocity curves plus fixed
- Pitch bend & Modulation assignable wheels
- Octave shift buttons
- PB1/2 buttons
- 4 keyboard zones programmable with controller filters and program changes
- 5 keyboard maps store all settings
PRESET CONTROLS
- 16 encoders
- 9 45mm faders
- 10 assignable LED buttons
- 11 dedicated transport buttons
- 20 preset locations store all settings including links to keyboard, pad and F-keys maps
PADS
- 12 pads with velocity and pressure sensitivity
- 7 velocity curves
- Note-learn
- Scale mode with 30+ scales and interval setting
- Velocity spread functions spreads the selected pad assignment over all 12 pads, at different velocity levels
- Transpose and Octave shift in both pad-map and scale mode
- Pads freely assignable in Reason mode
- Load or Save to any of 20 pad maps
F-KEYS
- 11 assignable Function Keys (accessible using shift and transport keys)
- Load or Save to any of 10 F-Keys maps
- F-Keys assignable even in 3 Reason modes
ADDITIONAL
- 100 mm ALPS motorized fader
- 6 dedicated assignable navigation buttons
- ASCII/QWERTY macros assignable to buttons and pads
- 3.5" high-resolution TFT display provides incredible navigation and user visibility
- Nektar DAW Integration
- Presets and setup files for major DAWs and VIs
CONNECTIONS
- Expression pedal 1/4" jack input (pedal not included)
- Foot switch (sustain) 1/4" jack input (pedal not included)
- MIDI output
- USB port for communication with computer
- USB Micro B connector for extra and external power
- Two USB ports or external USB power supply required to power entire unit. One USB port powers entire unit with the exception of the motorized fader
