- Capsule Type
Electret Condenser
- Frequency Response
40 Hz to 20 kHz
- Directivity
Omni-directional
- Sensitivity *[1]
-39.0 dB (11.2 mV)
- Output Impedance *[2]
2.5kΩ±30%, Unbalanced
- Dynamic Range
90 dB or more
- Signal-to-Noise Ratio *[3]
64 dB or more
- Inherent Noise *[4]
30 dB SPL or less
- Induction Noise From External Magnetic Field *[5]
5 dB SPL or less
- Wind Noise *[6]
40 dB SPL or less (with windscreen)
- Maximum Input Sound Pressure Level *[7]
- Connector
No connector (Pigtail)
- Mic Cable
9.8 feet
3 m
- Power Requirements
DC 1.1 V to 10.0 V
- Power Consumption
0.4 mA or less
- Dimensions *[8]
φ 5.6 X 12.5 mm (Mic head)
φ 1/4 X 1/2 inches (Mic head)
- Mass
Approx. 22.7 g
Approx. 0.8 oz
- Supplied Accessories
Single/horizontal type tie clip (1)
Metal-mesh type windscreen (1)
- Optional Accessories
Wind screen pack
Vertical clip pack
Safety pin type clip pack
Horizontal double-clip pack
Horiozntal single-clip pack
ECM-77 accessory kit
Colored wind screen kit
Black windscreen for ECM-77
