| Color/Finish |
|---|
| Body | Color |
Black |
|---|
| Size/Weight |
|---|
| Dimensions | Width |
992 mm (39-1/16”) |
|---|
| Height |
136 mm (5-3/8”) |
|---|
| Depth |
404 mm (15-7/8”) |
|---|
| Vikt | Vikt |
7.0 kg (15 lb, 7 oz) (not including batteries) |
|---|
| Control Interface |
|---|
| Keyboard | Number of Keys |
61 |
|---|
| Touch Response |
Yes (Soft, Medium, Hard, Fixed) |
|---|
| Typ |
Organ-style |
|---|
| Other Controllers | Pitch Bend |
Yes |
|---|
| Art. Switches |
Yes |
|---|
| Control Knobs |
2 |
|---|
| Display | Typ |
LCD |
|---|
| Backlight |
Yes |
|---|
| Panel | Language |
English |
|---|
| Voices |
|---|
| Tone Generation | Tone Generating Technology |
AWM Stereo Sampling |
|---|
| Polyphony | Number of Polyphony (Max.) |
64 |
|---|
| Preset | Number of Voices |
820 (294 Panel Voices + 28 Drum/SFX kits + 40 Arpeggio + 458 XGlite Voices) |
|---|
| Featured Voices |
3 Live! Voices, 9 Sweet! Voices, 6 Cool! Voices, 14 Super Articulation Lite Voices |
|---|
| Compatibility | GM |
Yes |
|---|
| XGlite |
Yes |
|---|
| Effects |
|---|
| Types | DSP |
DSP1: 41 types, DSP2: 12 types |
|---|
| Reverb |
12 types |
|---|
| Chorus |
5 types |
|---|
| Master EQ |
4 types |
|---|
| Functions | Dual/Layers |
Yes |
|---|
| Split |
Yes |
|---|
| Melody Suppressor |
Yes (w/ pan adjustment) |
|---|
| Crossfade |
Yes (between Internal Sound and External Audio) |
|---|
| Accompaniment Styles |
|---|
| Preset | Number of Preset Styles |
290 |
|---|
| Fingering |
Multi finger, Smart Chord |
|---|
| Style Control |
ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL, TRACK ON/OFF |
|---|
| Other Features | One Touch Setting (OTS) |
Yes |
|---|
| Expandability | Expansion Style |
10 |
|---|
| Compatibility |
Style File Format (SFF) |
|---|
| Groove Creator |
|---|
| Preset | Number of Groove |
35 |
|---|
| Number of Sections |
5 (4 Sections + 1 Musical Climax/Ending) |
|---|
| Songs |
|---|
| Preset | Number of Preset Songs |
30 |
|---|
| Recording | Number of Songs |
10 |
|---|
| Number of Tracks |
6 (5 Melody + 1 Style/Groove Creator) |
|---|
| Data Capacity |
Approx. 19,000 notes (when only “melody” tracks are recorded) |
|---|
| Compatible Data Format | Uppspelning |
SMF (Formats 0 & 1) |
|---|
| Recording |
Original File Format (SMF 0 conversion function) |
|---|
| USB Audio Recorder |
|---|
| Recording Time (max.) |
80 minutes (approx. 0.9 GB) per Song |
|---|
| Format | Playback |
WAV (44.1 kHz, 16 bit, stereo) |
|---|
| Recording |
WAV (44.1 kHz, 16 bit, stereo) |
|---|
| Quick Sampling |
|---|
| Sampling Type |
One-shot, Loop |
|---|
| Samples (Preset/User) |
4 |
|---|
| Sampling Time |
Approx. 9.6 sec |
|---|
| Sampling Sources |
AUX IN, MIC INPUT, USB audio interface, WAV format files |
|---|
| Sampling Format |
Original File Format (16 bit, stereo) |
|---|
| Sampling Rate |
44.1 kHz |
|---|
| Functions |
|---|
| USB audio interface |
44.1 kHz, 16 bit, stereo |
|---|
| Registration | Number of Buttons |
4 (x 8 banks) |
|---|
| Control |
Freeze |
|---|
| Overall Controls | Metronome |
Yes |
|---|
| Tempo Range |
11 – 280 |
|---|
| Transpose |
-12 to 0, 0 to +12 |
|---|
| Tuning |
427.0 – 440.0 – 453.0 Hz (approx. 0.2 Hz increments) |
|---|
| Octave Button |
Yes |
|---|
| Scale Type |
5 types |
|---|
| Miscellaneous | PIANO Button |
Yes (Portable Grand Button) |
|---|
| Other Functions |
Mega Boost, Motion Effect (57 types) |
|---|
| Voices | Harmony/Echo |
26 types |
|---|
| Arpeggio |
152 types |
|---|
| Storage and Connectivity |
|---|
| Storage | Internal Memory |
Approx. 1.72 MB |
|---|
| External Drives |
USB flash drive |
|---|
| Connectivity | DC IN |
12 V |
|---|
| AUX IN |
Stereo mini jack x 1 |
|---|
| Headphones |
Standard stereo phone jack x 1 |
|---|
| Sustain Pedal |
Yes |
|---|
| USB TO DEVICE |
Yes |
|---|
| USB TO HOST |
Yes |
|---|
| OUTPUT |
Standard phone jack x 2 |
|---|
| Microphone |
Standard phone jack x 1 |
|---|
| Amplifiers and Speakers |
|---|
| Amplifiers |
6 W + 6 W |
|---|
| Högtalare |
12 cm x 2 |
|---|
| Strömförsörjning |
|---|
| Strömförsörjning |
AC Adaptor PA-150 or an equivalent recommended by Yamaha, or six "AA" size alkaline (LR6), manganese (R6) or Ni-MH rechargeable (HR6) batteries |
|---|
| Strömförbrukning |
9 W (When using PA-150 AC adaptor) |
|---|
| Auto Power Off Function |
Off/5/10/15/30/60/120 (minutes) |
|---|
| Accessories |
|---|
| Included Accessories | Music Rest |
Yes |
|---|
| Song Book |
Download from Yamaha web site |
|---|
