- Type
Back electret condenser microphone
- Stereo type
MS (Mid-Side) stereo microphone
- Power supply
External power supply 40 V to 52 V
DC (IEC 61938 P48)
- Power consumption
Stereo: 3 mA or less x 2Ch
Monaural: 3 mA or less
- Output connector
Cannon XLR-3-12C type x2
- Dimensions
24 dia. x 137 mm (31/32 dia. x 5 1/2 in.)
- Mass
Approx. 160 g (5.6 oz.)
- Supplied accessories
Wind screen (1), Cable tie (1), Operating instructions (1), Warranty booklet (1)
- Frequency response
Stereo: 80 Hz to 20,000 Hz
Monaural: 70 Hz to 20,000 Hz
- Directivity
Uni-directional
- Output impedance
30 Ω ±20%, balanced
- Sensitivity (deviation ±3 dB)
Stereo: -32 dB
Monaural: -36 dB
- Signal-to-noise ratio
69 dB or more (IEC 179 A-weighted, 1 kHz, 1 Pa)
- Inherent noise
25 dB SPL or less
- Wind noise
45 dB SPL or less (with wind screen)
65 dB SPL or less (without wind screen)
- Induction noise from external magnetic field
0 dB SPL/1 x 10-7 T (1 mG) or less
- Maximum input sound pressure level
125 dB SPL or more (input level for 1% waveform distortion at 1 kHz, converted into equivalent input sound pressure level)
- Dynamic range
100 dB or more
- Operating temperature
0 °C to 50 °C (32 °F to 122 °F)
- Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
- 1)
0 dB=1 V/Pa, 1 kHz
- 2)
0 dB SPL = 20 μPa
